HotRod Henry 3d printer is already available! Buy now

What is awesome about HotRod Henry?

Huge printing volume

With 350mm (W) x 350mm (D) x 600mm (H) printing volume (over 73 litres!) you can create anything you want!

High quality prints

HotRod Henry has layer resolution 50 – 250 micron (0.35mm nozzle) which allows you to print not only huge but also detailed models.

All materials possible

HotRod Henry allows you to basically print with every thermoplastic material available on the market, i.e.:

  • PLA
  • ABS
  • flexible materials (rubber, NinjaFlex, Verbatim Primaloy)
  • co-polyesters (colorFabb XT and XT CF-20 containing carbon fiber)
  • composites (incl. colorFabb woodFill, copperFill, bronzeFill, bambooFill, brassFill)
  • polystyrene (HIPS)
  • polyamide (Nylon, Taulman 617, 645)
  • polycarbonate
  • PETT (Taulman t-glase)
  • any other termolastics up to 350°C

Unique design

HotRod Henry with its unique, retro style definitely stands out from the crowd and fits every interior – both modern and classic one!

All-metal extruder

It contains no volatile plastic parts, features an all-metal hot end (0.35 or 0.5mm nozzle) and heats up to 350° C!

Closed machine

Mounted windows help HotRod Henry to preserve high temperature inside the casing which is important when printing with certain materials.

Well-lit chamber

All the chamber is well-lit by LEDs mounted on three sides, which allows you to see everything clearly even in dark rooms.

Every slicing software possible

You can use whatever slicing software you desire. With HotRod Henry you can use your favourite program for slicing, e.g. Simplify 3d, Cura, Repetier-Host.

Stiff and robust construction

Super build quality of HotRod Henry will allow you to print without breaks and always get repeatable results!

Heated bed

Aluminum heated bed heats over 110° C and has a nice tempered glass on top of it.

Other features

  • OLED display & keypad
  • SD card support
  • USB port

Specifications

  • Extruder: Innovative “all metal” by Micron 3DP  featuring a detachable filament guide and nozzle module “DFGNM”.
  • Printing technology: FFF = Fused Filament Fabrication
  • Build volume : 350mm (W) × 350mm (D) × 600 mm (H)
  • Layer resolution: 50 – 250 micron (0.35mm nozzle)
  • Filament diameter: 1,75 mm
  • Build plate: aluminum heated bed with tempered glass top (up to 110ºC)

  • PLA
  • ABS
  • flexible rubber
  • composites (WoodFill, CopperFill, Bronzefill)
  • HIPS (polystyrene)
  • polyamide (Nylon)
  • polycarbonate
  • all other thermoplastics up to 350ºC

  • Dimentsions without spool: 610mm (width) × 640mm (depth) × 970mm (height)
  • Dimentsions with filament spool on: 610mm (width) × 740mm (depth) × 970mm (height)
  • Packaging size: 700mm (width) × 700mm (depth) × 1100mm (height)
  • Weight: 60 kg

  • 230V
  • 60Hz
  • 2,5A
  • 500W

  • USB connectivity
  • LCD and keypad
  • SD card support
